SPECIFICATIONS
- Type: 1/10th, Brushless Sensored ESCÂ
- Applications: 1/10th Drift car, Sensorless or Sensored brushless Motors, KV Rating/T Count ≥8.5T
- Recommended motor: Best when paired with D10 Premium brushless motor
- Cont/Peak Current (i): 100A/800A
- Input Voltage: 2S Lipo
- BEC output: 5-7.4V,5A
- Wires / Connectors: Black-13AWG-250mm*2
- Output connectors: 3.5mm male plug
- Fan size: 30x30x10mm
- Fan Voltage Range: 5-7.4V Powered by BEC
- ESC Programming by: LCD Program Box (PC) / OTA Programmer (Independent programming port)
- Firmware Upgrade: Supported
- ESC size/Weight: 40.7×35.0x32.0mm(w/Fan) / 95g (w/wires)
Specification
| Manufacturer | Hobbywing |
|---|---|
| Part Number | HW30112614 |
| EAN | 6938994408592 |
| Power Rating | Upto 100 Amps |
| ESC Mode | Multi Profile |
| Battery Compatibility | LiPo |
| ESC Type | For Brushless Motors |
| Motor Connector Type | No Connector |
| Battery Connector Type | No Connector |
| Motor Compatibility Type | Sensored |
| Max Lipo Volt Rating | 7.4v / 2s |
